MSI The B850 GAMING PLUS WIFI is an excellent motherboard for gamers and other demanding users looking for a reliable and high-performance platform for their AMD Ryzen processor. It offers a wealth of connectivity options, a powerful power supply, and many features that make gaming and other uses smoother and more enjoyable. The motherboard features several high-speed interfaces, such as PCIe 5.0 and 3 x M.2, ensuring fast data transfer and short loading times. Wi-Fi 7 support ensures a fast and reliable wireless network connection, while the 5G LAN port provides a stable and fast connection via a wired connection.
Features:
- Lightning Gen 5: The latest PCIe 5.0 solution with a bandwidth of up to 128 Gb/s for maximum transfer speeds.
- EZ M.2 Shield Frozr II: The new tool-free design makes installing or removing M.2 SSDs and the Shield Frozr much easier.
- 3 x M.2 slots: The motherboard features 3 x M.2 slots, one of which is a PCIe 5.0 solution, reinforced with M.2 Shield Frozr.
- EZ PCIe Clip II: Allows for easy removal of the graphics card by pressing a tail-shaped latch with a single finger, even in tight chassis spaces.
- Enhanced cooling: The "MSI:n" extended PWM heatsink and improved circuit layout ensure that even high-end processors run at full speed.
- Latest DDR5 memory: A major leap forward in DDR performance with the latest DDR5 memory and MSI Memory Boost technology.
- 5G networking solution: Premium 5G LAN delivers a better networking experience.
- Pre-installed I/O shield: Better EMI protection and easier installation.
- Wi-Fi 7: The latest wireless solution featuring a new 320 MHz channel, achieving a maximum transfer speed of 5.8 Gbps—2.4 times faster than Wi-Fi 6/6E.
- Audio Boost: Treat your ears to studio-grade audio that delivers the most immersive sound experience.
Technical Specifications:
- Processor Support: AMD Ryzen™ 9000 / 8000 / 7000 series processors
- Processor socket: AMD Socket AM5
- Chipset: AMD B850
- Expansion slots: 1x PCIe 5.0 x16, 1x PCIe 4.0 x16, 2x PCIe 3.0 x1
- Display outputs: Supports 4K@60Hz HDMI™ 2.1 FRL, DisplayPort 1.2 HBR (requires integrated graphics)
- Memory: 4 DIMM, Dual Channel DDR5 - 8200+MT/s (OC)
- Storage: 1 x M.2 Gen5 x4 128Gbps, 1 x M.2 Gen4 x4 64Gbps, 1 x M.2 Gen4 x2 32Gbps, 4x SATA 6Gbps
- USB ports: 3 x USB 10Gbps (1 Type-C + 1 Type-A), 6 x USB 5Gbps (5 Type-A + 1 Type-C), 8 x USB 2.0 Type-A
- Network: Realtek 5G LAN, Wi-Fi 7, Bluetooth 5.4
- Audio: 8-channel (7.1) HD Audio with Audio Boost 5
- AM5 motherboard
- AMD B850 chipset
- 5G LAN, Wi-Fi 7, Bluetooth 5.4
- 3 x M.2
- 4 x DDR5
This text was automatically translated, errors may be present.
4711377285438EAN:
